Starlink BlueSolar PWM-Light Charge Controller 12/24V-30A
Description
Victron BlueSolar PWM-Light Charge Controller 12V/24V - 30A
• Load output with low battery voltage disconnect function.
• Lighting control function, one timer only.
• Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.
• Three stage battery charging (bulk, absorption, float), not programmable.
• Load output protected against over load and short circuit.
• Protected against reverse polarity connection of the solar array and/or battery.
• Day/night timing options: see manual for details
Battery Voltage : 12/24 V with automatic system voltage detection
Victron BlueSolar PWM-Light Charge Controller 12V/24V - 30A
• Load output with low battery voltage disconnect function.
• Lighting control function, one timer only.
• Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.
• Three stage battery charging (bulk, absorption, float), not programmable.
• Load output protected against over load and short circuit.
• Protected against reverse polarity connection of the solar array and/or battery
• Day/night timing options: see manual for details
| Parameters | Values |
| Model | 12/24-30 |
| Battery Voltage | 12/24 V with automatic system voltage detection |
| Rated charge current | 30A |
| Automatic load disconnect | Yes |
| Maximum solar voltage | 28V / 55V |
| Self-consumption | < 10 mA |
| Load output | Manual control + low voltage disconnect |
| Protection | Battery reverse polarity (fuse) Output short circuit Over temperature |
| Overload protection | Shut down after 60 s in case of 130% load |
| Shut down after 5 s in case of 160% load | |
| Short circuit: immediate shut down | |
| Grounding | Common positive |
| Operating temp. range | -20 to +50°C (full load) |
| Humidity (non-condensing) | Max 95% |
| Charge voltage 'absorption' | 14.2V / 28,4V |
| Charge voltage 'float' | 13.8V / 27,6V |
| Low voltage load disconnect | 11,2V / 22,4V |
| Low voltage load reconnect | 12,6V / 25,2V (manual) |
| 13,1V / 26,2V (automatic) | |
| Protection class | IP20 |
| Terminal size | 5 mm² / AWG10 |
| Weight | 0,15kg |
| Dimensions (h x w x d) | 70 x 133 x 33,5 mm (2.8 x 5.3 x 1.3 inch) |
| Safety | IEC 62109-1 |
| EMC | EN 61000-6-1, EN 61000-6-3, ISO 7637-2 |
