Starlink Solar Panel 305W-20V Mono 1658x1002x35mm
Description
Victron Energy has a strong, unrivalled reputation for technical innovation, reliability, and build quality. Their products are widely considered to be a professional choice for independent electric power. Efficiently combining two or more distinct power sources is what they do best. Their products include sinewave inverters, sinewave inverters/chargers, battery chargers, DC/DC converters, transfer switches, battery monitors and more.Victron 20V 305W Mono Solar Panel
- Low voltage-temperature coefficient enhances high-temperature operation.
- Exceptional low-light performance and high sensitivity to light across the entire solar spectrum.
- 25-Year limited warranty on power output and performance.
- 5-Year limited warranty on materials and workmanship.
- Sealed, waterproof, multi-functional junction box gives high level of safety.
- High performance bypass diodes minimize the power drop caused by shade.
- Advanced EVA (Ethylene Vinyl Acetate) encapsulation system with triple-layer back sheet meets the most stringent safety requirements for high-voltage operation.
- A sturdy, anodized aluminium frame allows modules to be easily roof-mounted with a variety of standard mounting systems.
- Highest quality, high-transmission tempered glass provides enhanced stiffness and impact resistance.
- High power models with pre-wired quick-connect system with MC4 (PV-ST01) connectors.
Product Specifications
|
20V 305W Poly Solar Panel |
|
|
Module |
SPM043052000 |
|
Nominal Power (± 3% tolerance) |
305W |
|
Cell Type |
Monocrystalline |
|
Number of Cells in Series |
72 |
|
Maximum System Voltage |
1000V |
|
Temperature Coefficient of PMPP (%) |
-0.45/°C |
|
Temperature Coefficient of Voc (%) |
-0.35/°C |
|
Temperature Coefficient of Isc (%) |
+0.04/°C |
|
Temperature Range |
-40°C to +85°C |
|
Surface Maximum Load Capacity |
200 kg/m² |
|
Allowable Hail Load |
23 m/s, 7.53 g |
|
Junction Box Type |
PV-LH0701 |
|
Length of Cable/ Connector |
900 mm / MC4 |
|
Output Tolerance |
+/-3% |
|
Frame |
Aluminium |
|
Product Warranty |
5 Years |
|
Warranty on Electrical Performance |
10 years 90% + 25 years 80% of power output |
|
Dimensions |
1658 x 1002 x 35mm |
|
Net Weight |
18.4kg |
|
Electrical Data Under STC |
|
|
Nominal Power (PMPP) |
305W |
|
Maximum Power Voltage (VMPP) |
32.5V |
|
Maximum Power Current (IMPP) |
9.38A |
|
Open Circuit Voltage (Voc) |
39.7V |
|
Short Circuit Current (Isc) |
10.27A |
