Starlink Orion-Tr 24/12-5 (60W) DC-DC converter Retail
Description
Victron Orion-Tr 24/12-5 (60W) DC-DC converterHigh efficiency-Using synchronous rectification, full load efficiency exceeds 95%.
IP43 protection-When installed with the screw terminals oriented downwards.
Screw terminals-No special tools needed for installation.
| Model | Orion-Tr |
| Input voltage range | 18-35V |
| Output voltage | 12.7V |
| Efficiency | 95% |
| Continuous output current | 5A |
| Max. Output current | 7A |
| Galvanic isolation | no |
| Off load current | < 20mA |
| Operating temperature range (derate 3% per °C above 40°C) | -20 to +55°C |
| DC connection | Screw terminals |
| Maximum cable cross-section | 3,3 mm² AWG12 |
| Weight kg | 0,09 |
| (lbs) | -0.2 |
| Dimensions hxwxd in mm,(hxwxd in inches) | 53x51x27 (2.1x2x1.1) |
