MultiPlus-II 48/10000/140-100/100 230V

CODE: PMP483105000

$2,839.00

In stock

Due to this being a complex product requiring 240V power to be wired into the device directly, we are unable to sell this item online. Please see us in store to purchase or contact us to discuss your options.

Please note that this device must be legally installed by a licensed electrician. Installation completed by any other unlicensed individual may result in serious injury or death of those operating or installing the device.

Description

The MultiPlus-II is a multifunctional inverter/charger with all the features of the MultiPlus, plus an external
current sensor option which extends the PowerControl and PowerAssist function to 50A resp. 100A.
The MultiPlus-II is ideally suited for professional marine, yachting, vehicle and land based off-grid applications.
It also has built-in anti-islanding functionality, and an increasingly long list of country approvals for ESS application.
Several system configurations are possible.

he MultiPlus-II will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery.

ESS: Energy Storage Systems

The MultiPlus-II is the key component in a Victron ESS system, providing the flexibility to combine with MPPT Solar Chargers or Grid-tie PV Inverters. For examples and more detailed information see the ESS (Energy Storage System) manual.

Uninterrupted AC power (UPS function)

In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption.

Remote Monitoring and Control

When coupled with a GX device (e.g. Cerbo GX) you can monitor and control your Multi and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop or PC for multiple operating systems. There is no end to the level of control, from adjusting your Multi to auto starting a backupgenerator and more…"

Specifications

Product Model	PMP483105000
Imput Voltage	48v
Output (V)	230
Output (VA)	10000
Output (W)	8000
Charger Size (ah)	140
Warranty (years)	5

MultiPlus-II Inveter/Charger Data Sheet (MultiPlus-II-Data-Sheet.pdf, 670 Kb) [Download]

After Sale Support

Our knowledgeable staff are happy to take any enquiries about your purchase
